Construction Drawings That Turn Vision Into Buildable Plans | Great Hall Design

At Great Hall Design, we bridge the gap between inspiration and execution with detailed, contractor-ready construction drawings. Whether you're working with your own builder or collaborating through our design-build partners, our drawings ensure your project is clearly communicated, code-compliant, and ready to move forward.

Construction drawings (also known as architectural or permit drawings) are the detailed documents your builder, engineer, or local permitting office needs to actually build your home or renovation. These are more than pretty plans—they’re precise technical documents that communicate layout, structure, dimensions, materials, and specifications.

Done well, construction drawings reduce delays, prevent costly misunderstandings, and give every stakeholder—from contractors to city planners—clarity and confidence in your project.

For Homeowners, Builders, and Design-Build Teams

Our drawings are designed to serve three audiences:

1.     Homeowners—who want clarity, confidence, and a buildable plan to take to a contractor.

2.     Builders/Contractors—who need clean, well-organized documents for accurate estimating and execution.

3.     Design-Build Collaborations—where we coordinate drawings with construction partners to streamline the process from start to finish.

Whether you already have a builder or want our guidance in choosing one, we’re here to help move your project from idea to action.

Simplifying the Permitting Process

Navigating local codes and permit approvals can feel overwhelming—but that’s where we come in. We prepare drawing sets with permitting in mind, aligning with local regulations in West Virginia, Virginia, and surrounding jurisdictions.

If your municipality requires specific documentation or redlines, we’ll work with you and your builder to revise and resubmit as needed.
